LIJU Roj thiab Roj Hlau hlua siv nyob rau hauv Offshore Mooring, Anchoring, Towing, Workwire, Laum Kab, Casing kab, Xuab zeb kab, Riser Tensioner
Khoom Taw Qhia
LIJU muab txhua qhov loj me ntawm cov khoom zooRoj thiab roj hlau hlua, ua kom muaj kev ua tau zoo tshaj plaws thiab kev txiav txim siab ntawm kev ruaj ntseg.LIJU Roj thiab Roj Hlau Ropeyog tsim nyob rau hauv advanced-of-the-art technology thiab undergo nruj zoo tswj ntsuas.LIJU Roj thiab Roj Hlau Ropeyog tsim los nrog ze qhov ntev kam rau ua kom yooj yim rau lub jerk-free txav ntawm elevator.
Cov qauv pom zoo
6X19S 35X7 6X37M
Khoom siv
Offshore Mooring, Anchoring, Towing, Workwire
Drill Line, Casing kab, Xuab zeb kab
Riser Tensioner
Txoj hlua nkag mus offshore
Khoom Parameter Thiab Paub meej
| Txoj kab uas hla / mm | Qhov hnyav (kg / 100m) | Nominal tensile lub zog ntawm steel hlau hlua / mpa | ||||||||||||
| 1570 | 1670 | 1770 | 1870 | 1960 | 2160 | |||||||||
| FC | WSC | FC | WSC | FC | WSC | FC | WSC | FC | WSC | FC | WSC | FC | WSC | |
| 12 | 54.7 | 60.2 | 74.6 | 80.5 | 79.4 | 85.6 | 84.1 | 90.7 | 88.9 | 95.9 | 93.1 | 100 | 103 | 111 |
| 13 | 64.2 | 70.6 | 87.6 | 94.5 | 93.1 | 100 | 987 | 106 | 104 | 113 | 109 | 118 | 120 | 130 |
| 14 | 74.5 | 81.9 | 102 | 110 | 108 | 117 | 114 | 124 | 2 | 130 | 127 | 137 | 140 | 151 |
| 16 | 97.3 | 107 | 133 | 143 | 141 | 152 | 50 | 161 | 158 | 170 | 166 | 179 | 182 | 197 |
| 18 | 123 | 135 | 168 | 181 | 179 | 193 | 189 | 204 | 200 | 216 | 210 | 226 | 231 | 249 |
| 20 | 152 | 167 | 207 | 224 | 220 | 238 | 234 | 252 | 247 | 266 | 259 | 279 | 285 | 308 |
| 22 | 184 | 202 | 251 | 271 | 267 | 288 | 283 | 304 | 299 | 322 | 313 | 338 | 345 | 372 |
| 24 | 219 | 241 | 298 | 322 | 317 | 342 | 336 | 363 | 355 | 383 | 373 | 402 | 411 | 443 |
| 26 | 257 | 283 | 350 | 378 | 373 | 402 | 395 | 426 | 417 | 450 | 437 | 472 | 482 | 520 |
| 28 | 298 | 328 | 406 | 438 | 432 | 466 | 458 | 494 | 484 | 522 | 507 | 547 | 559 | 603 |
| 30 | 342 | 376 | 466 | 503 | 496 | 535 | 526 | 567 | 555 | 599 | 582 | 628 | 642 | 692 |
| 32 | 389 | 428 | 531 | 572 | 564 | 609 | 598 | 645 | 632 | 682 | 662 | 715 | 730 | 787 |
| 34 | 439 | 483 | 599 | 646 | 637 | 687 | 675 | 728 | 713 | 770 | 748 | 807 | 824 | 889 |
| 36 | 492 | 542 | 671 | 724 | 714 | 770 | 757 | 817 | 800 | 863 | 838 | 904 | 924 | 997 |
| 38 | 549 | 604 | 748 | 807 | 796 | 858 | 843 | 910 | 891 | 961 | 934 | 1010 | 1029 | 1110 |
| 40 | 608 | 669 | 829 | 894 | 882 | 951 | 935 | 1010 | 987 | 1065 | 1030 | 1120 | 1140 | 1230 |
Peb Qhov Zoo
1. Txhua Qhov Loj: 14mm txog 160mm (7/16 nti rau 6.299 nti)
2. Zoo ua haujlwm rau khoov qaug zog thiab puas
3. High breaking load
4. Cov qauv zoo heev stability
5. Lub chaw pabcuam thoob ntiaj teb thiab kev hloov pauv sai
Txog Peb
LIJU yog tus thawj cojRoj thiab roj hlau hluamanufacturers hauv Suav teb. Peb cov chaw xa khoom thoob ntiaj teb thiab cov kev pabcuam kev pabcuam tau tsim kho kom zoo los muab peb cov neeg siv khoom ua haujlwm zoo elevator hlau hlua thiab cov kev daws teeb meem.
